Description
Achieve more layout points all day every day
The Leica iCON iCR80 construction total station keeps its ‘eye’ on only one thing: the user’s target. Layout more points per day thanks to ATRplus, the most robust automated-aiming, lock and re-lock technology in the market. iCR80 is especially useful in congested sites with many distractions, such as reflections, machines and people moving around. Challenging and changing site conditions should not be an obstacle.
The iCON iCR80 allows users to:
- Layout lines for footings or chalk line for formwork on foundation
- Layout points on blinding layer, such as pipe insert or cut-outs before pouring concrete
- Layout true design objects based on federated and enriched models
- MEP layout of wall penetrations for pipes, hanger locations for HVAC and duct work, inserts and slits for sheet metal work
- Control a wide variety of construction machines, such as curb and gutter or milling machines, asphalt or concrete pavers, and graders or dozers
The iCON iCR80 guarantees layout efficiency with the most reliable, simple and automatic set up procedure, industry-leading prism lock, and flexible handling of fully rendered 3D design models in the field. This sophisticated, one-person total station offers an ‘all-in-one’ solution for every purpose – especially the difficult ones, allowing you to speed up your workflow.
Ability to layout complex designs
Laying out intricate designs is a difficult task construction crews face every day. Complex geometries must be simplified by converting them to lines and rectangles, which means the staked point will not represent the true design when brought to the field. With iCON build Layout Objects app integrated into the solution, users can lay out straight from 3D models by selecting an object, like a column or pipe, simply by tapping on it in the controller and benefit from the flexible creation of layout work packages for effective work progress management.
Most stable prism lock
The iCR80 and iCR80S come with automated target aiming based on ATRplus technology which enables automatic aiming, locking and re-locking onto targets. ATRplus keeps the instrument locked on the prism whether the prism is on a surveying pole or on a moving machine.
Dynamic Lock
You no longer need to stand still and wait for the instrument to find and lock to the prism. Thanks to ATRplus and Dynamic Lock, the iCR80 and iCR80S get the best automation performance with a larger area for searching and locking onto a moving target.
Automated set up
Stay confident and efficient with the most reliable, simple and automated set up routine. With no user interaction required, the intelligent Setup Pilot app orientates the total station with only the push of a button, allowing you to begin work almost immediately. The successful setup completion is visually communicated, indicating layout can begin.
